Thermoplastic polyurethane (TPU) tubing is rapidly becoming the go-to solution for fluid transfer, pneumatic control, medical applications and more. Its exceptional combination of flexibility, durability, chemical-resistance and processability positions it at the forefront of high-performance tubing solutions.
Key Product Parameters of TPU Tubing
| Parameter | Typical Specification |
|---|---|
| Material | Thermoplastic polyurethane (TPU) |
| Shore Hardness | ~70 A to 95 A (depending on grade) |
| Temperature Range | From approx –40 °C up to ~80 °C (continuous), short-term peaks higher |
| Chemical Resistance | Excellent resistance to oils, greases, many solvents |
| Abrasion & Wear | High abrasion resistance due to elastomeric structure |
| Biocompatibility | Available in medical-grade formulations for catheters, fluid-delivery |
| Typical Applications | Medical, industrial fluid/air supply, automotive, pneumatic systems |
TPU tubing refers to tubes made from thermoplastic polyurethane elastomers. These materials combine the processability of thermoplastics (easy extrusion, moulding) with elastomeric qualities (flexibility, elasticity).
Functionally, TPU tubing serves as a conduit for fluids (liquid or gas), for pneumatic or hydraulic systems, for medical device fluid-delivery, for industrial automation, and in harsh environments where wear, tear, chemical exposure or temperature fluctuations are present.
Key functions include:
Conveying fluids or gases with minimal deformation or failure
Withstanding repeated flexing or bending cycles without fatigue
Operating in chemically aggressive or abrasive environments
Meeting regulatory/biocompatibility demands in medical/biomedical settings
Enabling miniaturised multi-lumen formats or specialised geometries for precision delivery
There are several compelling reasons behind the growing preference for TPU tubing:
a) Flexibility combined with strength & abrasion resistance
TPU’s molecular structure (hard segments + soft segments) grants it excellent elasticity, high tensile strength, and high abrasion resistance.These qualities mean that TPU tubing can tolerate bending, movement, friction and wear better than many rigid or conventional elastomer tubes.
b) Chemical and environmental resistance
TPU formulations resist oils, greases, many solvents, hydrolysis (for appropriate grades) and maintain flexibility at lower temperatures.For tubing applications this means longer life, less maintenance and reliability in harsh conditions.
c) Processability and customisation
TPU can be extruded, moulded, co-extruded, over-moulded and formed into complex geometries efficiently. This allows tubing manufacturers to produce single-lumen, multi-lumen, coloured, or medical-grade tubing to suit customer requirements.
d) Growing market demand and trend-driven growth
The market for multi-lumen TPU tubing is experiencing strong growth, particularly in medical and industrial sectors. For example, the multi-lumen TPU tubing market is projected to grow at a CAGR of roughly 6-7% driven by minimally invasive procedures and industrial automation.This momentum makes TPU tubing a strategic material choice for forward-looking OEMs.
e) Versatility across sectors
From medical catheters to pneumatic lines in automation to automotive fluid lines, TPU tubing spans multiple industries. This breadth of use reduces dependency on niche applications and spreads risk.
Manufacturing Process
Material selection & compounding: Choosing the correct grade of TPU (polyester-based, polyether-based, etc.) depending on needed properties such as hydrolysis resistance, low temperature flexibility or chemical resistance.
Extrusion/co-extrusion: Tubing is typically manufactured by extrusion through dies, possibly with co-extrusion (e.g., multi-lumen) or over-molding for specialty parts.
Post-processing: Cooling, annealing (to relieve stress), cutting to lengths, and in medical cases sterilisation or cleanroom packaging.
Quality control: Testing for dimensional accuracy, wall thickness, burst pressure, flexibility, biocompatibility (if medical).
Application integration: Tubing is integrated into assemblies—e.g., catheter sets, pneumatic manifolds, industrial fluid systems.
Selecting the Right TPU Tubing
Define the application environment: temperature extremes, chemical exposure, mechanical flexing, sterilisation (medical)
Choose the correct TPU grade: For example polyester-based TPU offers higher mechanical strength & abrasion resistance; polyether-based offers better hydrolysis resistance (important for wet/humid environments)
Specify tubing geometry: Single vs multi-lumen, inner/outer diameters, wall thickness, required bend radius
Check regulatory/biocompatibility if medical use: Some TPUs are certified for food/medical contact.
Consider production & cost trade-offs: TPU offers high performance but design and material cost may be higher than basic PVC or rubber tubing—however lifecycle cost may be lower.
Future-proofing: Look at trends such as lower environmental footprint, embedded sensors in tubing, or advanced multi-lumen configurations. The market report suggests such innovations.
Application Examples
Medical devices: multi-lumen fluid delivery, catheters, respiratory connectors.
Industrial automation: fluid and pneumatic lines subject to repeated motion, abrasion, in corrosive environments.
Automotive: under-hood hoses, sensor conduits, flexible fluid lines where temperature, vibration and chemical exposure are factors.
Consumer/electronic: flexible tubing for wearable devices, cable sheaths, smart-device fluid or gas channels.
Future Trends
Miniaturisation and multi-lumen tubing: Demand for smaller diameters with multiple internal channels is rising, especially in medical devices.
Embedded sensing and smart tubing: Integration of sensors (flow, pressure) inside or alongside tubing for real-time analytics in automation and medical systems.
Sustainability and bio-based TPUs: As environmental regulation tightens, formulation of TPU with reduced carbon footprint and better recyclability is gaining interest.
Higher performance TPUs: Enhanced temperature resistance, flame-retardant grades, hybrid materials combining TPU with other polymers for specific extreme use cases.
Growth in emerging regions: Asia-Pacific, Latin America and other developing regions continue to drive growth for TPU tubing as industrialisation and medical infrastructure expand.
Challenges
Raw material cost volatility: TPU resins can fluctuate in cost, affecting margins.
Competition from alternative materials: Materials such as silicone, PVC, other thermoplastic elastomers compete with TPU especially where cost is more important than high performance.
Regulatory hurdles for medical-grade tubing: Biocompatibility, sterilisation, ISO standards impose higher cost and lead time.
Processing complexity for advanced tubing (multi-lumen, embedded sensors): Higher tooling cost, precision manufacturing required.
Sustainability concerns: While TPU offers performance, recycling and end-of-life management are still evolving.
Brand Proposition and Call to Action
With the above in mind, companies seeking reliable, high-performance tubing solutions should consider partnering with experienced manufacturers who understand materials, manufacturing and industry applications. One such provider is Micro-tube Polymer Materials Co., Ltd. Their expertise and product range in TPU tubing make them well placed to support both current needs and future trends.
For more information and to assess how their TPU tubing solutions can fit into your application, Contact Us at Micro-tube Polymer Materials Co., Ltd.
-
